Our Delrin CNC Machining Services

At Yigu Technology, we specialize in top-tier Delrin CNC Machining—crafting precise, durable parts from Polyoxymethylene (POM) (also known as Acetal Resin), a versatile Engineering Plastic. Our expertise in CNC Milling, CNC Turning, and tailored surface treatment ensures your custom components leverage Delrin’s unique benefits: low friction, high stiffness, and exceptional dimensional stability. Whether you need rapid prototypes for industrial tools or high-volume production for automotive parts, we turn your designs into reliable solutions that drive efficiency.

Get Free Quote

What Is Delrin CNC Machining?

Delrin CNC Machining is a computer-controlled manufacturing process that shapes Delrin—the brand name for Polyoxymethylene (POM), a high-performance Acetal Resin and Engineering Plastic—into custom, precise parts. Unlike manual machining, it uses automated tools to follow digital blueprints, ensuring consistency in critical Material Properties like low coefficient of friction, high strength-to-weight ratio, and resistance to chemicals.

This Machining Process is ideal for Delrin because it avoids common issues like warping or chipping that can compromise part performance. By using tools such as CNC mills and lathes, it transforms raw Delrin stock (sheets, rods, or blocks) into components ranging from tiny electronic connectors to large industrial gears—all while preserving Delrin’s ability to withstand repeated use and harsh environments.

Our Delrin CNC Machining Capabilities

Yigu Technology’s Delrin CNC Machining services are designed to meet the diverse needs of industries relying on high-performance plastic parts. We combine advanced equipment with skilled craftsmanship to deliver parts that meet even the strictest standards. Below is a detailed breakdown of our core capabilities:

Capability	Key Features	Typical Applications
Precision Machining	Achieves Precision Tolerances as tight as ±0.005mm; preserves Delrin’s low friction properties	Medical device components, small gears
Custom Machined Parts	Creates fully customized designs (from 2D sketches to 3D CAD models); supports low-to-high volumes	Industrial tool components, consumer goods parts
High-Tolerance Machining	Complies with ISO 9001 and ANSI Y14.5 Tolerance Standards; verified via rigorous inspection	Aerospace fasteners, automotive sensors
Complex Part Production	Handles intricate geometries (undercuts, thin walls, threaded features) without damaging Delrin	Electronic enclosures, robotic components
Rapid Prototyping	Turns designs into physical Delrin parts in 1–3 days; ideal for design testing and validation	Product prototypes, small-batch industrial tools
Production Machining	Scales to 30,000+ units/month; maintains consistent quality across batches	Mass-produced automotive components, consumer goods hinges
Quality Assurance	In-line checks (CMM, optical scanners) and post-production inspections; 99.8% defect-free rate	All industries, especially medical and aerospace

The Delrin CNC Machining Process

Our Delrin CNC Machining process is a structured, quality-focused workflow designed to maximize Delrin’s performance while ensuring precision. Each step is optimized to minimize waste and deliver reliable results:

Design & File Preparation: We convert customer CAD files (STEP, IGES) into machine-readable G-code, accounting for Delrin’s low melting point (175–185°C) to avoid overheating during cutting.

Machine Setup: Technicians handle Tool Selection (carbide endmills or high-speed steel tools) and secure Delrin stock with non-marring clamps to prevent surface scratches and ensure stability.

CNC Milling/Turning: CNC Milling shapes flat or 3D parts (e.g., industrial gear teeth), while CNC Turning creates cylindrical components (e.g., automotive shafts or bushings).

Drilling Operations: Drilling Operations create precise holes (as small as 0.4mm) with controlled feed rates to prevent delamination— a common issue with Delrin if drilled too quickly.

Cutting Techniques: We use medium-speed cutting (150–250 m/min) with compressed air cooling to avoid melting; for Glass-Filled Delrin, we slow speeds to 100–180 m/min to protect tools.

Grinding Processes: Optional Grinding Processes smooth rough edges and refine dimensions, critical for parts requiring tight fits (e.g., medical device components).

Surface Treatment: Final steps like polishing or coating enhance performance (see Section 5).

Inspection: Every part undergoes Measurement Techniques (CMM for dimensions, surface roughness testers for finish) to ensure compliance.

Below is a table of key process parameters for different Delrin types:

Delrin Type	Optimal Cutting Speed (m/min)	Feed Rate (mm/min)	Coolant Type
Delrin (Unfilled POM)	180–250	200–350	Compressed air
Acetal Copolymer	160–220	180–300	Compressed air
Acetal Homopolymer	150–200	150–280	Compressed air
Glass-Filled Delrin	100–180	120–220	Compressed air
Lubricated Delrin	170–230	190–320	Compressed air

Materials Used in Delrin CNC Machining

Choosing the right Delrin grade is critical to part performance—each type offers unique benefits for specific applications. We work with a range of high-quality Delrin materials:

Material	Key Properties	Typical Industry Applications
Delrin (POM)	Low coefficient of friction, high stiffness, good dimensional stability	All industries (base material)
Acetal Copolymer	Excellent chemical resistance, low moisture absorption	Automotive fuel system parts, industrial valves
Acetal Homopolymer	Higher tensile strength, better fatigue resistance than copolymer	Medical device shafts, high-load gears
Glass-Filled Delrin	30–40% higher stiffness, improved heat resistance	Aerospace structural components, heavy-duty industrial tools
Lubricated Delrin	Enhanced wear resistance (contains PTFE or silicone)	Bearings, sliding components, robotic joints
Specialty Delrin Grades	Customized (e.g., flame-retardant, FDA-compliant, conductive)	Electronic enclosures (flame-retardant), medical implants (FDA-compliant)

Surface Treatment for Delrin CNC Parts

Surface Treatment enhances Delrin parts’ durability, functionality, and appearance—critical for applications requiring wear resistance or chemical protection. Our key offerings include:

Polishing: Creates a smooth finish (Ra 0.02–0.1μm) to reduce friction; ideal for sliding components like bearings or gears.

Coating: Applies protective layers (e.g., PTFE coating for extra low friction, epoxy coating for chemical resistance); common in automotive and industrial parts.

Painting: Uses Delrin-specific paints for color coding or branding (e.g., consumer goods hinges); ensures paint adheres without peeling.

Sandblasting: Creates a matte surface (Ra 1.0–3.0μm) to improve grip or hide minor surface imperfections; used for industrial tool handles.

Heat Treatment: Reduces internal stress in thick Delrin parts to prevent warping over time—critical for large components like industrial machine frames.

Surface Finishing: Final steps like deburring (removing small plastic burrs) and chamfering (smoothing sharp edges) ensure parts are safe for handling and assembly.

Anodizing: Though rare for Delrin, we offer specialized anodizing-like treatments for parts needing enhanced corrosion resistance in harsh environments (e.g., marine industrial equipment).

Tolerances: Ensuring Precision in Delrin Parts

In Delrin CNC Machining, Tolerances are critical—even small dimensional variations can ruin a part’s fit (e.g., an automotive bushing) or functionality (e.g., a medical device component). We adhere to strict standards and use advanced Inspection Methods to guarantee accuracy:

Key Tolerance Metrics for Delrin Parts

Tolerance Type	Typical Range	Measurement Tool	Industry Requirement Example
Precision Tolerances	±0.005–±0.03mm	Coordinate Measuring Machine (CMM)	Medical device shafts (must align with other components)
Tight Tolerances	±0.03–±0.08mm	Digital calipers	Aerospace fasteners (fit with metal brackets)
Dimensional Accuracy	±0.08–±0.3mm	Optical scanners	Industrial gear teeth (ensure smooth rotation)

Our Inspection Methods include:

CMM (for 3D dimensional checks on complex parts like gears or enclosures)

Optical comparators (to verify thread accuracy and small features)

Surface roughness testers (to confirm finish quality for low-friction parts)

Chemical resistance testing (for parts used in harsh environments like automotive fuel systems)

Advantages of Delrin CNC Machining

Delrin CNC Machining offers unique benefits over other manufacturing methods (e.g., injection molding, 3D printing) that make it ideal for Delrin parts:

High Strength-to-Weight Ratio: Delrin is 5x stronger than many standard plastics (e.g., acrylic) but 30% lighter than aluminum—perfect for automotive or aerospace parts where weight matters.

Low Coefficient of Friction: Delrin’s friction coefficient (0.15–0.3) is comparable to lubricated metal, eliminating the need for extra lubrication in sliding components like bearings.

High Stiffness: Delrin maintains its shape under heavy loads (flexural modulus of 2.8–3.5 GPa), making it ideal for industrial gears and structural parts.

Good Dimensional Stability: Delrin has low thermal expansion (11–16 μm/m°C) and minimal moisture absorption (<0.2%), ensuring parts don’t warp in temperature or humidity changes.

Chemical Resistance: Delrin resists oils, fuels, and most solvents—suitable for automotive fuel system parts or industrial equipment exposed to chemicals.

Cost-Effective Production: No expensive molds (unlike injection molding) makes it affordable for low-to-medium volumes (1–5,000 units); fast setup reduces lead times.

Design Flexibility: Handles complex geometries (threaded holes, undercuts, thin walls) that are hard to achieve with metals or other plastics—great for custom industrial tools.

Industry Applications of Delrin CNC Machining

Our Delrin CNC Machined parts power critical operations across 7 major industries, each leveraging Delrin’s unique properties:

Industry	Key Applications	Delrin Grade Used	Why Delrin CNC?
Automotive	Fuel system components, bushings, door hinges, sensor housings	Acetal Copolymer, Lubricated Delrin	Chemical resistance, low friction, durability
Aerospace	Fasteners, valve components, interior structural parts	Glass-Filled Delrin, Acetal Homopolymer	High stiffness, dimensional stability
Electronics	Connector housings, switch components, PCB supports	Delrin (POM), Flame-Retardant Specialty Grades	Low moisture absorption, flame resistance
Medical	Surgical tool handles, device shafts, implant components (FDA-compliant)	FDA-Compliant Delrin, Acetal Homopolymer	Biocompatibility, easy sterilization
Industrial Equipment	Gears, bearings, conveyor parts, valve seats	Glass-Filled Delrin, Lubricated Delrin	High load capacity, wear resistance
Consumer Goods	Zipper sliders, toy components, appliance knobs	Delrin (POM), Colored Specialty Grades	Cost-effective, durability for daily use
Sporting Goods	Golf club components, bicycle parts, fishing reel parts	Lubricated Delrin, Acetal Homopolymer	Low friction, impact resistance

Case Studies: Success with Delrin CNC Machining

Case Study 1: Automotive Fuel System Bushings

Challenge: A leading automotive client needed chemical-resistant bushings for fuel systems (tolerances ±0.02mm) that could withstand oils and fuels without degrading.

Solution: We used Acetal Copolymer (excellent chemical resistance) and CNC Turning with precise feed rates to avoid delamination. Post-production, we tested parts for chemical exposure and dimensional accuracy.

Result: Bushings passed 5,000+ hours of fuel exposure testing; 100% compliance with automotive standards (ISO 14692); delivered 20,000 units in 7 days.

Case Study 2: Medical Surgical Tool Shafts

Challenge: A medical device maker required FDA-compliant, high-strength shafts for surgical tools (must withstand repeated sterilization and tight tolerances ±0.01mm).

Solution: Delrin CNC Machining of FDA-compliant Acetal Homopolymer (high fatigue resistance) with polishing (for smooth handling) and heat treatment (to reduce stress).

Result: Shafts passed 1,500+ autoclave cycles without warping; 99.9% defect-free rate; delivered prototypes in 2 days, production in 5 days.

Case Study 3: Industrial Gear Components

Challenge: An industrial client needed durable gears for conveyor systems (must handle heavy loads, low friction, tolerances ±0.03mm).

Solution: CNC Milling of Glass-Filled Delrin (high stiffness) with lubricated coating (for extra wear resistance). We used optical scanners to verify gear tooth accuracy.

Result: Gears lasted 3x longer than standard plastic gears; reduced conveyor maintenance costs by 40%; 15,000 units produced with 0 defects.

Why Choose Yigu Technology for Delrin CNC Machining?

When you partner with Yigu Technology for Delrin CNC Machining, you get more than just parts—you get a trusted manufacturing ally with deep expertise in Delrin’s unique properties. Here’s why clients choose us:

Expertise in Delrin Machining: 10+ years of focus on Delrin (POM) and Acetal Resin machining; our engineers understand how to optimize processes for Delrin’s low melting point and friction properties.

High-Quality Products: 99.8% defect-free rate; ISO 9001 and medical-grade (ISO 13485) certifications; every part inspected via CMM and surface testing.

Experienced Machinists: Our team has an average of 9+ years in Delrin CNC Machining; trained on specialized equipment (e.g., high-precision Haas CNC machines) for Delrin’s unique needs.

Excellent Customer Service: Dedicated account managers; 24-hour response time for queries; free design consultations to optimize parts for machining (e.g., reducing warping risks).

Fast Turnaround Times: Prototypes in 1–3 days; production runs in 4–8 days (25% faster than industry averages); rush orders available for urgent projects.

Competitive Pricing: No hidden fees; volume discounts for 1,000+ units; material waste reduced by 15% via optimized toolpaths (passing savings to you).

Commitment to Innovation: We invest in new technologies (e.g., 5-axis CNC for complex Delrin parts) and test new Specialty Delrin Grades yearly to expand our capabilities.

FAQ

Can you machine Delrin parts with FDA-compliant grades for medical applications?

Yes! We offer FDA-compliant Delrin (POM) grades (meets FDA 21 CFR Part 177.2450) specifically for medical applications like surgical tools or implant components. These grades undergo additional testing for biocompatibility and sterilization resistance, ensuring compliance with medical standards (ISO 13485).

What is the difference between Acetal Copolymer and Acetal Homopolymer for CNC machining?

Acetal Copolymer offers better chemical resistance and lower moisture absorption, making it ideal for automotive fuel parts or industrial valves. Acetal Homopolymer has higher tensile strength and fatigue resistance, suiting medical device shafts or high-load gears. Our team can help you choose the right grade based on your part’s function and environment.

How do you prevent Delrin parts from warping during or after CNC machining?

Warping is a common concern with Delrin (POM) due to its low melting point and sensitivity to temperature changes, but we use a 4-step approach to minimize this risk:
First, controlled machining parameters: We adjust cutting speeds and feed rates based on the Delrin grade (e.g., slower speeds for Glass-Filled Delrin) and use compressed air cooling to keep temperatures below 170°C—well below Delrin’s melting point (175–185°C). This prevents localized overheating that causes internal stress.
Second, strategic part fixturing: During Machine Setup, we use non-marring, evenly distributed clamps to secure Delrin stock without applying excessive pressure. For large or thin parts, we add support brackets to avoid bending during cutting.
Third, post-machining heat treatment: After machining, we subject thick or complex parts to a low-temperature annealing process (60–80°C for 1–2 hours). This relieves residual stress that would otherwise cause warping as the part cools.
Fourth, proper storage and handling: We package finished Delrin parts in temperature-stable containers and advise clients to store them in environments with consistent humidity (40–60%) and temperature (18–24°C). This prevents moisture absorption or thermal expansion that can alter dimensions.
With these steps, we’ve reduced warping rates to less than 0.5% across all Delrin projects—even for large parts like industrial machine frames or thin components like electronic connector tabs.
